Specification
| Fingerprint Type | Optical |
| Resolution | 500dpi |
| Gray Scale | 256gray |
| Platen Size (W x L) | 16.4 x 19.4 mm |
| Sensing Area (W x L) | 13 x 14.8 mm |
| Auto Sensing | O |
| Speed | 25 frames Per second(fps) |
| Interface | USB 2.0 |
| Operating Temperature | 0 ~ 60℃ |
| Operating Humidity | 10 ~ 90%, non-condensing |
| Dimension (W x H x D) | 70.4 x 39.8 x 17.6 mm |
| Certifications | ROHS, IP65(Sensor Surface), KC, CE, FCC |
| Image Format | WSQ, RAW, BMP |
| Templates Type | VIRDI, ISO 19794-2, ANSI 378 |
| LFD | O |
| Operating System | Windows, Android |
| Card Type | X |
