Specification

Authentication Method Biometric
Dust/ Water Resistance X
Memory Max Users card (1:1)/(1:N) 200,000
Fingerprint
(Base on one finger
enrollment per user)
1:1 200,000
1:N 50,000
Face
(Base on five Face
enrollment per user)
1:1 X
1:N X
Iris
(Base on 2 eyes (L/R)
enrollment per user)
1:1 200,000
1:N 20,000
Templates Fingerprint 1:1 400,000
1:N 100,000
MAX Templates per Finger 2
MAX Finger per User 10
Face 1:1 X
1:N X
MAX Templates per Finger X
Iris 1:1 400,000
1:N 40,000
MAX Templates per Eyes 2
MAX Templates per User 4
Logs 10,000,000
Images 20,000
Communication with server TCP/IP
other USB
Wireless LAN(Wi-Fi) Optional
Wiegand OUT O
RS232 O
RS485 O
Wiegand IN O
Display LCD 5”Color Touch
Backlight 0
Embedded Camera Dual
Card 125khz-EM O
HID Prox O
HID iclass O
13.56MHz Smart Card O
Keypad Touch Screen
Function keys SOFT
Door Phone VoIP
FP Sensor (Platen Area) Nscan-FM : 16.6 x 21.6mm
Resolution 500dpi
Dimension (W) X (H) X (D) mm 160.6 x 214 x 45.4mm
FRR /FAR 0.1% / 0.0001%
Operating Temperature -20 ~ 60℃
Opertating Software (Server solution) UBio Alpeta
